Ti-5Al-2.5Sn Titanium Alloy

Ti-5Al-2.5Sn is a medium-strength, single-phase alpha titanium alloy containing approximately 5% aluminum and 2.5% tin. It offers good fracture toughness at room and elevated temperatures, favorable weldability, and reliable thermal stability. As a non-heat-treatable alloy, it is generally supplied in the annealed condition and is valued for applications requiring a combination of mechanical performance and elevated-temperature capability.

The alloy exhibits limited room-temperature forming plasticity, so sheet forming is generally performed at elevated temperatures. Its good welding characteristics allow the use of inert-gas-shielded processes, including tungsten inert gas (TIG) and metal arc welding. Available semi-finished forms include plates, sheets, bars, forgings, discs and rings, as well as cast products. The low-interstitial variant, Ti-5Al-2.5Sn ELI (TA7ELI), is also used in applications requiring improved low-temperature fracture toughness.

Ti-5Al-2.5Sn alpha titanium alloy
Ti-5Al-2.5Sn alpha titanium alloy.
Mechanical Properties

Mechanical Properties of Ti-5Al-2.5Sn

Ti-5Al-2.5Sn is a medium-strength alpha titanium alloy known for its good fracture toughness, ductility and mechanical stability at elevated temperatures. Its mechanical properties depend on product form, material condition, processing history and testing temperature.

Mechanical Property Specification Minimum Typical Value
Tensile Strength (Rm) 828 MPa 860–970 MPa
0.2% Yield Strength (Rp0.2) To be verified 820–900 MPa
Elongation (A50) 10% 12–18%
Reduction of Area 25% 25–40%
Hardness — 320–350 HV

Typical values are provided for reference and may vary depending on product form, material condition, processing history, specimen orientation and testing conditions. Minimum requirements should be verified against the applicable material specification.

Technical Data

Physical and Chemical Properties of Ti-5Al-2.5Sn

Ti-5Al-2.5Sn exhibits characteristic thermal, electrical and chemical properties. The following data summarize its density, melting range, thermal conductivity, specific heat capacity, thermal expansion, electrical resistivity, magnetic behavior and resistance to oxidation and corrosion.

Basic Physical Properties

Property Value
Density (g/cm³) 4.42
Melting Temperature Range (°C) 1540–1650

Thermal Conductivity

Temperature (°C) 20 100 200 300 400 500 600 700 800
Thermal Conductivity (W·m⁻¹·K⁻¹) 8.8 9.6 10.9 12.2 13.4 14.7 15.9 17.2 18.4

Specific Heat Capacity

Temperature (°C) 100 200 300 400 500 600 700 800
Specific Heat Capacity (J·kg⁻¹·K⁻¹) 503 545 566 587 628 670 712 796

Coefficient of Linear Expansion

Temperature Range (°C) 20–100 20–200 20–300 20–400 20–500 20–600 20–700 20–800 20–900
Coefficient (10⁻⁶ K⁻¹) 8.5 8.9 9.1 9.3 9.5 9.6 9.7 10.1 10.5
Temperature Range (°C) 100–200 200–300 300–400 400–500 500–600 600–700
Coefficient (10⁻⁶ K⁻¹) 9.3 9.7 10 10.3 10.5 11

Electrical Resistivity

Temperature (°C) 20 100 200 300 400 500 600
Electrical Resistivity (μΩ·m) 1.38 1.69 1.75 1.80 1.84 1.87 1.88

Magnetic Properties

Ti-5Al-2.5Sn is generally classified as a non-magnetic titanium alloy for practical engineering applications.

Oxidation Resistance

Ti-5Al-2.5Sn exhibits oxidation behavior comparable to industrially pure titanium and Ti-6Al-4V under similar exposure conditions. Its oxidation performance depends on temperature, exposure duration and the surrounding atmosphere.

Corrosion Resistance

Ti-5Al-2.5Sn offers good corrosion resistance under atmospheric conditions and in seawater. However, it can be susceptible to hot-salt stress corrosion under specific high-temperature and tensile-stress conditions. Reported test data indicate stress corrosion after 100 hours at 316°C under a stress of 207 MPa in an environment heavily covered with artificial seawater salt deposits.

The listed values are reference data. Actual physical and chemical properties may vary with material composition, product form, microstructure and test conditions. Verify the original data source and applicable test conditions before using these values for engineering calculations.

Chemical Analysis

Chemical Composition of Ti-5Al-2.5Sn

Ti-5Al-2.5Sn is an alpha titanium alloy primarily composed of titanium, aluminum and tin. Its chemical composition includes controlled alloying elements and impurity limits, which influence its mechanical properties, thermal stability and processing characteristics.

Grade Alloy Element Impurities ≤
Ti Al Sn Fe Si C N H O Other Element
Single Total
Ti-5Al-2.5Sn Balance 4.0–6.0 2.0–3.0 0.5 0.1 0.05 0.015 0.2 0.1 0.4

Note: The listed composition values are provided for reference. Confirm the applicable element ranges and impurity limits against the relevant Ti-5Al-2.5Sn material specification and certified material test report before use in engineering or procurement.

Phase Transformation

Phase Transformation and Microstructure of Ti-5Al-2.5Sn

The phase transformation behavior of Ti-5Al-2.5Sn is closely related to its heating temperature and cooling conditions. Understanding its transformation temperatures and resulting microstructures is important for controlling material properties during heat treatment and processing.

Phase Transformation Temperatures

Ti-5Al-2.5Sn exhibits distinct phase transformation temperature ranges associated with changes between the α and β phases. The reported transformation temperatures are as follows:

Phase Transformation Temperature Range (°C)
β ↔ α + β 1040–1090
α ↔ α + β 930–970

Microstructure Evolution

The microstructure of Ti-5Al-2.5Sn is influenced by the heating temperature and cooling rate. Different thermal conditions result in distinct phase compositions and microstructural characteristics.

Equilibrium Microstructure

Below the α ↔ α + β transformation temperature, approximately 950°C, the equilibrium microstructure is predominantly single-phase α.

Rapid Cooling from the α + β Region

Rapid cooling from the upper α + β phase region, such as around 1010°C, can produce α′ martensite accompanied by a small amount of α phase.

Cooling from the β Region and Subsequent Annealing

Rapid cooling from the β phase region can produce an α-phase microstructure. During subsequent annealing, any α′ phase gradually decomposes and transforms into the α phase.

Manufacturing Performance

Manufacturing Process and Deformation Behavior of Ti-5Al-2.5Sn

The manufacturing characteristics of Ti-5Al-2.5Sn depend on melting conditions, heat treatment parameters and hot deformation processes. Proper control of these factors helps maintain the alloy's microstructure and mechanical properties throughout production.

01

Melting and Casting Process

Ingot production and electrode preparation

Ti-5Al-2.5Sn ingots are produced by vacuum consumable electrode arc melting, with at least two melting cycles to promote chemical homogeneity. Aluminum and tin are introduced in the form of an Al-Sn master alloy.

Alloying Addition Al-Sn Master Alloy

Aluminum and tin are added together in the form of an Al-Sn master alloy.

Electrode Welding Argon-Shielded Plasma Welding

Used for consumable electrode assembly. Argon tungsten arc welding is strictly prohibited for this operation.

02

Heat Treatment System

Annealing and stress relief conditions

Annealing

Temperature 700–850°C
Plates 10–120 min
Bars and Forgings 1–4 h

Both product forms are air-cooled after annealing.

Stress Relief Annealing

General Products 540–650°C
Holding Time 15–360 min
Castings 600–800°C · 1–4 h

Air cooling or furnace cooling, depending on product form.

03

Thermal Deformation Process

Hot-working control and temperature requirements

During the final hot-working operation below the β-transus temperature, a deformation amount of approximately 25–40% or greater is recommended to obtain good mechanical properties. If subsequent reheating is required, such as for thermal straightening, the reheating temperature should remain at least 90°C below the β-transus temperature.

Final Deformation 25–40% or greater

Recommended deformation amount during the final hot-working operation.

Reheating Temperature At least 90°C below β-transus

Temperature restriction for subsequent reheating operations, such as thermal straightening.

Thermal Deformation Process Specifications

Forging Operation Heating Temperature (°C) Final Forging Temperature (°C) First-Pass Deformation (%)
Ingot Blooming 1180 ≥900 30–50
Blank Pre-Deformation 1100 ≥850 40–70
Hammer Die Forging 1020–1100 ≥900 40–70
Press Die Forging 1020 ≥850 40–70

Deformation Resistance at Different Deformation Rates

The deformation resistance of Ti-5Al-2.5Sn varies with temperature and deformation rate. The following data show the maximum deformation resistance under different test conditions, with resistance generally decreasing as the deformation temperature increases.

Deformation Temperature (°C) Deformation Rate 1 Deformation Rate 2 Deformation Rate 3 Deformation Rate 4
800 222 320 365 452
900 205 262 285 313
1000 80 93 105 117
1100 35 59 62 80

Tensile Properties at Heat Distortion Temperature

The elevated-temperature tensile properties of Ti-5Al-2.5Sn illustrate changes in tensile strength, elongation and reduction of area across different test temperatures.

Form Diameter (mm) Condition Sampling Direction Temperature (°C) Tensile Strength (MPa) Elongation (%) Reduction of Area (%)
Rods 22 Annealed L 700 252 86.2 82.2
800 160 140.8 95.6
850 121 140 94
900 88 170 96.5
1000 35 78 63
Applications

Applications of Ti-5Al-2.5Sn Titanium Alloy

Ti-5Al-2.5Sn is used in specialized aerospace and engineering applications where moderate strength, good weldability, fracture toughness and thermal stability are important. Its stable alpha-phase structure supports service in selected elevated-temperature and low-temperature environments, making it suitable for components with demanding thermal and structural requirements.

Aircraft engine and thermal system components made from titanium alloy
03

Aircraft Engines

Ti-5Al-2.5Sn can be used in selected aircraft engine and thermal-system components where resistance to elevated-temperature exposure and structural stability are required. Component selection depends on operating temperature, stress level, service duration and the specified material condition.

  • Aircraft engine structural parts
  • Thermal-system support components
  • Elevated-temperature fittings
  • Specialized aerospace hardware
Cryogenic engineering equipment and low-temperature titanium alloy components
02

Low-Temperature Engineering

The alloy's fracture toughness and low-temperature mechanical performance make it relevant to selected cryogenic engineering applications. Extra-low interstitial (ELI) grades, where specified, can be considered when improved toughness at very low temperatures is required.

  • Cryogenic structural components
  • Low-temperature support structures
  • Specialized pressure-system components
  • Low-temperature aerospace equipment
Thermal equipment components made from Ti-5Al-2.5Sn titanium alloy
03

Thermal Equipment

Ti-5Al-2.5Sn can be considered for selected thermal equipment components where resistance to elevated-temperature exposure and structural stability are important. Material selection depends on operating temperature, stress level, service duration and the specified material condition.

  • Heat-resistant structural components
  • Thermal-system support parts
  • Elevated-temperature fittings
  • Specialized industrial components
Why AlloyHit

Why Choose AlloyHit for Ti-5Al-2.5Sn Titanium Alloy?

Ti-5Al-2.5Sn is an alpha titanium alloy valued for its fracture toughness, weldability and stable mechanical behavior across a range of service temperatures. Choosing the appropriate material involves more than selecting an alloy grade; product form, material condition, processing history and application requirements all influence performance. AlloyHit helps customers evaluate these factors when sourcing Ti-5Al-2.5Sn products for specialized engineering applications.

Understanding Ti-5Al-2.5Sn Material Characteristics

Ti-5Al-2.5Sn is an alpha-phase titanium alloy containing approximately 5% aluminum and 2.5% tin. Its material characteristics differ from those of alpha-beta alloys, particularly in terms of phase structure, heat-treatment response and elevated-temperature stability. We can review the requested grade, chemical composition limits and applicable specifications to help clarify the material requirements for your project.

Sheet, Plate and Custom Product Supply

Ti-5Al-2.5Sn can be supplied in different product forms according to project needs and manufacturing feasibility. Requirements may involve sheet, plate, strip, bar, rod, forging or other specified formats. Share your target thickness, dimensions, tolerances, quantity and technical drawings so that suitable product options can be evaluated for your application.

Forming, Welding and Heat Treatment Guidance

The processing behavior of Ti-5Al-2.5Sn depends on temperature, deformation conditions and the initial material state. Its forming characteristics, welding procedures and annealing requirements should be considered together when planning component fabrication. We can review your specified processing requirements and discuss relevant material conditions and technical considerations before an order is placed.

Material Traceability and Technical Requirements

For applications with defined quality requirements, material identity and supporting documentation are important throughout procurement and production. Depending on the order specification and available inspection services, documentation may include chemical composition results, mechanical test data, dimensional records and material test reports. Required standards, inspection scope and acceptance criteria can be reviewed against your project specifications.

Project-Specific Material Selection and Support

Ti-5Al-2.5Sn is considered for applications requiring a combination of fracture toughness, weldability and thermal stability. The standard grade and extra-low interstitial (ELI) variant serve different material requirements, particularly where low-temperature toughness is important. Provide your operating temperature, service environment, product dimensions and performance criteria so our team can review the appropriate material option. Contact AlloyHit at info@alloyhit.com to discuss your requirements and request a quotation.

MATERIAL COMPARISON

Ti-5Al-2.5Sn vs Other Titanium Alloys

Different titanium alloys are developed to meet specific combinations of mechanical strength, fracture toughness, thermal stability, corrosion resistance and fabrication requirements. Ti-5Al-2.5Sn is an alpha titanium alloy with characteristics that differ from commercially pure titanium and alpha-beta grades such as Ti-6Al-4V. Understanding these differences helps engineers evaluate material suitability for aerospace structures, low-temperature components and other specialized applications.

01 ALLOY COMPARISON

Ti-5Al-2.5Sn vs Pure Titanium

Commercially pure titanium grades rely primarily on the properties of unalloyed titanium and are commonly selected for their corrosion resistance, ductility and forming characteristics. Ti-5Al-2.5Sn contains aluminum and tin as alloying elements, providing higher strength than commercially pure grades while retaining an alpha-phase structure. The addition of these elements also influences its thermal and mechanical behavior.

The distinction is particularly relevant when balancing strength requirements against fabrication needs. Commercially pure titanium is often suitable for corrosion-resistant equipment and formed components, whereas Ti-5Al-2.5Sn is considered for applications requiring greater strength, fracture toughness and more stable performance under selected thermal conditions.

Selection Guidance

Consider commercially pure titanium for applications prioritizing corrosion resistance, ductility and ease of forming. Evaluate Ti-5Al-2.5Sn when higher strength, fracture toughness and thermal stability are important to the component design.

02 ALLOY COMPARISON

Ti-5Al-2.5Sn vs Ti-6Al-4V

Ti-5Al-2.5Sn and Ti-6Al-4V represent two different titanium alloy systems. Ti-5Al-2.5Sn is an alpha alloy containing aluminum and tin, while Ti-6Al-4V is an alpha-beta alloy strengthened through aluminum and vanadium additions. Their different phase structures lead to differences in heat-treatment response, forming behavior and mechanical performance.

Ti-6Al-4V is generally selected where high strength and broad structural versatility are required. Ti-5Al-2.5Sn is considered when alpha-alloy characteristics, weldability, fracture toughness and performance in selected low- or elevated-temperature environments are important. The appropriate choice depends on the component design and specified operating conditions.

Selection Guidance

Choose Ti-6Al-4V for applications requiring high strength and the benefits of an alpha-beta alloy system. Consider Ti-5Al-2.5Sn when weldability, alpha-phase stability and low-temperature toughness are more relevant to the application.

03 GRADE COMPARISON

Ti-5Al-2.5Sn vs Ti-5Al-2.5Sn ELI

Ti-5Al-2.5Sn ELI is an extra-low interstitial variant of the standard Ti-5Al-2.5Sn alloy. Its controlled interstitial content, particularly oxygen, nitrogen and carbon, is intended to improve ductility and fracture toughness, especially at low temperatures. Both grades retain the same basic alpha-alloy system, but their composition limits and resulting property requirements differ according to the applicable specifications.

Standard Ti-5Al-2.5Sn may be suitable for general aerospace and engineering applications where its established mechanical and thermal characteristics meet the design requirements. The ELI variant is considered for more demanding low-temperature service, where toughness and resistance to brittle fracture are particularly important. Grade selection should account for product form, material condition and specified testing requirements.

Selection Guidance

Consider standard Ti-5Al-2.5Sn for applications where conventional grade requirements are sufficient. Evaluate Ti-5Al-2.5Sn ELI when lower interstitial limits and enhanced low-temperature toughness are required by the application or material specification.

Comparing titanium grades for a specific engineering project? Provide your operating temperature, mechanical requirements, product form, dimensions and applicable specifications. AlloyHit can review your material requirements and discuss suitable Ti-5Al-2.5Sn supply options. Contact AlloyHit for a Ti-5Al-2.5Sn quotation.

Frequently Asked Questions

Frequently Asked Questions About Ti-5Al-2.5Sn

Q1: What type of titanium alloy is Ti-5Al-2.5Sn?

A: Ti-5Al-2.5Sn is an alpha titanium alloy containing approximately 5% aluminum and 2.5% tin by weight. Unlike alpha-beta alloys such as Ti-6Al-4V, it has an alpha-phase structure and is not conventionally strengthened through solution treatment and aging. It is valued for its fracture toughness, weldability and stable mechanical behavior under selected service conditions.

Q2: What is the difference between Ti-5Al-2.5Sn and Ti-6Al-4V?

A: The primary difference is their alloy system and microstructure. Ti-5Al-2.5Sn is an alpha alloy containing aluminum and tin, whereas Ti-6Al-4V is an alpha-beta alloy containing aluminum and vanadium. Ti-5Al-2.5Sn is often considered for applications emphasizing weldability, fracture toughness and thermal stability, while Ti-6Al-4V is widely selected for its higher strength and broad structural applications. The final choice depends on operating conditions and design requirements.

Q3: Is Ti-5Al-2.5Sn suitable for low-temperature applications?

A: Yes. Ti-5Al-2.5Sn is used in selected low-temperature engineering applications because of its fracture toughness and mechanical performance at reduced temperatures. Its extra-low interstitial (ELI) variant is particularly relevant when enhanced low-temperature toughness is required. Material selection should consider the minimum service temperature, product condition, interstitial content and applicable testing requirements.

Q4: Can Ti-5Al-2.5Sn be welded?

A: Ti-5Al-2.5Sn can be welded using suitable titanium welding procedures. Gas tungsten arc welding (GTAW/TIG) and other qualified processes may be considered depending on product thickness and joint configuration. Effective inert-gas shielding is essential to protect the weld metal and heat-affected zone from atmospheric contamination. Surface preparation, shielding coverage and post-weld requirements should be established for the specific application.

Q5: What heat treatment is used for Ti-5Al-2.5Sn?

A: Annealing and stress-relief treatments are commonly used to adjust the material condition and reduce residual stresses in Ti-5Al-2.5Sn products. Unlike heat-treatable alpha-beta alloys, this alpha alloy is not conventionally strengthened through solution treatment and aging. Treatment temperature, holding time and cooling method depend on product form, dimensions, prior processing and the applicable specification.

Q6: What manufacturing processes are used for Ti-5Al-2.5Sn products?

A: Ti-5Al-2.5Sn can be processed through hot working, forging, rolling, machining and other fabrication operations. Sheet and plate production may involve controlled hot and cold rolling, intermediate annealing and final surface treatment. Processing temperatures and deformation schedules need to be selected according to the required dimensions, material condition and mechanical properties.

Q7: What product forms are available in Ti-5Al-2.5Sn?

A: Ti-5Al-2.5Sn products can be sourced in several forms, including sheet and plate, rod and bar, tube and pipe, and wire. Product availability, dimensional ranges and tolerances depend on manufacturing feasibility and supply conditions. Customers should specify the required product form, dimensions, quantity and material condition when requesting a quotation.

Q8: What information is needed to order Ti-5Al-2.5Sn titanium alloy?

A: To prepare a suitable quotation, provide the alloy grade, product form, dimensions, tolerances, order quantity and required delivery condition. Please also identify any applicable standards, mechanical property requirements, inspection criteria and documentation needs. For low-temperature applications, specify the minimum service temperature and whether an ELI grade is required. Send your technical drawings or project specifications to info@alloyhit.com for further discussion.
