Thin, flat vanadium products with precise thickness control, ideal for applications requiring lightweight material with high strength-to-weight ratio.
Precision thicknessSmooth surfaceExcellent flatnessCustom sizesVarious finishes
Common Applications
- Battery components
- Electrode materials
- Thin film substrates
- Precision engineering
Tthicker vanadium products designed for structural applications requiring high strength, durability, and resistance to extreme temperatures.
High structural strengthThick section integrityHigh temp resistanceLarge format availableCustom machining
Common Applications
- Nuclear components
- High temp structures
- Aerospace parts
- Chemical processing
Custom Vanadium Sheet & Plate Solutions
We offer tailored vanadium sheet and plate solutions to meet your specific application requirements, with capabilities for precision cutting, shaping, and finishing.
Specifications of Vanadium Sheet & Plate
Our high purity vanadium sheets & plates are manufactured to precise specifications, with custom options available to meet your exact requirements.
| Parameter | Standard Range | Tolerance |
| Thickness | 0.1mm - 100mm | ±0.005mm - ±0.1mm |
| Width | 10mm - 600mm | ±0.2mm |
| Length | 10mm - 2000mm | ±0.3mm - ±1.0mm |
| Surface Finish | Mill, Ground, Polished | Ra 0.05μm – 1.6μm |
| Flatness | - | 0.1mm/m – 0.3mm/m |
Manufacturing Process of Vanadium Sheet & Plate
Our specialized manufacturing process ensures the highest quality vanadium sheets and plates with precise dimensions and exceptional purity.
1. High Purity Ingot Production
Vanadium metal of specified purity is melted under vacuum and cast into ingots with controlled grain structure.
2. Breakdown Rolling
Ingots are heated and subjected to initial hot rolling to reduce thickness and establish the basic sheet/plate form.
3. Intermediate Annealing
Material undergoes controlled atmosphere annealing to relieve stresses and maintain ductility during processing.
4. Cold Rolling
Precision cold rolling reduces material to final thickness with tight tolerance control, enhancing surface finish and dimensional accuracy.
5. Final Annealing
Final heat treatment in high-purity vacuum or inert gas atmosphere to achieve desired mechanical properties.
6. Finishing & Inspection
Sheets and plates undergo precision cutting, surface finishing, and rigorous inspection to ensure quality and dimensional accuracy.
Manufacturing Capabilities of Vanadium Sheet & Plate
Testing Procedures of Sheet & Plate
Dimensional Inspection
Laser measurement systems verify thickness, width, and length to ensure compliance with tight tolerances.
Chemical Analysis
GDMS and OES analysis confirm purity levels and detect trace elements down to parts per million.
Mechanical Testing
Tensile, hardness, and bend testing verify mechanical properties meet specifications.
Surface Inspection
Visual and ultrasonic inspection ensures surface quality and detects any defects
Contact Us
If you have any questions or needs regarding pure Vanadium Sheet products, please feel free to contact us and we will provide you with professional consulting services.
